162 • HRVS-DN Communication (Profibus protocol)
_____________________________________________________________________________________________
17.10 Stop Parameters
Parameter # Range Default
Soft_Stop_Curve 40 0..11 (6..11 are for Tacho only) 1 (Standard)
Deceleration_Time 41 0..90 0 (Seconds)
Final_Torque 42 0..10 0 (Minimum)
Coast Down Delay 43 Off (9) 10..3600 9 (Off)
Reserved 43..47
17.11 Dual Adjust Parameters
Parameter # Range Default
DA Initial Voltage /
DA Initial Current
48
10..80 % of full voltage /
100..400 % of FLA
30 /
100 % of FLA
DA Current Limit 49 100..700 400 % of FLA
DA Acceleration Time 50 1..90 10 (Seconds)
DA Deceleration Time 51 0..90 0 (Seconds)
DA Motor FLA 52 20..1800 150 (Amp.)
Reserved 53..55
17.12 Fault Parameters
Parameter # Range Default
UV & PL Auto_Reset 56 0..1 (0 - No, 1 - Yes) 0 (No)
Under_Current_Reset 57 10..120 (&121=off) 121 (Off)
By-Pass_Open_Trip 58 0 / 1 (0 – Disable,1 - Enable)
1 (Enable)
Trip_after_By-Pass 59 0 / 1 (0 – Disable,1 - Enable)
1 (Enable)
By-Pass_Auto_Reset 60 0 – No, 1 – Yes
0 (No)
Set_Curve_To_0 61 0 / 1 (0 – Disable,1 - Enable)
1 (Enable)
Power On & No Start 62 0 / 1 (0 – Disable,1 - Enable)
1 (Enable)
Insulation_Alarm 63
1(Off) – 100 (10 Mohm) 1 (Off)
Insulation_Trip 64
1(Off) – 100 (10 Mohm) 1 (Off)
Phase Sequence 65 0 – Pos., 1 – Neg., 2 – Ignore
0 (Positive)
Reserved 66..71
17.13 I/O Programming
Parameter # Range Default
Prog. Input #7 (thermal 7) 72
0..3
0 – Test
1 – Reset
2 – Multi Soft Stop - consult the
factory
3 – Current Control - consult the
factory
1 (Reset)
Prog. Input #8 (thermal 8) 73 0..1 (0=D.Adj.,1=Reset) 0 (Dual Adjust)
Fault Relay Type 74 0..1 (0=Fault, 1=Fault-Fail Safe) 0 (Fault)
Immediate Realy Type 75 0..1 (0=Immediate, 1=shear pin) 0 (Immediate)
Realy On Delay 76 0..3600 0 (Seconds)
Realy Off Delay 77 0..3600 0 (Seconds)
Analog output 78 0..1 (0 - Normal, 1 - Inverted) 0 (Normal)
Reserved 79
17.14 Communication Parameters
Parameter # Range Default
Comm. Protocol 80 0 – Modbus, 1-Profibus 1 – Profibus
Modbus Baud Rate 81 12..96 (*100) 192 (19200 bps)
Parity Check 82 0/1/2 (Even / Odd / No) 0 (Even)
Profibus_Network 83 0..126 (0-Off) 0 (Off)
S. Link Parameters Save 84 0 (Disable), 1 (Enable) 0 (Disable saving)
