Solcon HRVS-DN series User Manual

175 • HRVS-DN Communication (DeviceNet™)
_______________________________________________________________________________________________
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
12 Turn Bypass On
at
121-250 % of
Motor FLA
Only with
relay PCB
for
optional
sync
motor
start
Get/Set 40036
13 Min Time To
Bypass
3-60 3 Sec Get/Set 40037
18.12.3 Common Services
Service
Code
Implemented for Service Name
Class Level Instance Level
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
18.13 Stop Settings Object (73HEX – 1 Instance)
18.13.1 Class Attributes (Instance 0)
Attribute
ID
Name DeviceNet
Data Type
Data Value Access Rule
1 Revision UINT 1 Get
18.13.2 Instance Attributes (Instance 1)
Attribut
e ID
Name Range Default
Value
Access
Rule
Modbus
Address
1 Soft Stop Curve 0-11 (6-11
are for
Tacho
only)
1 (Standard) Get/Set 40041
2 Deceleration
Time
0-90 0 (Seconds) Get/Set 40042
3 Final Torque 0-10 0 (Minimum) Get/Set 40043
4 Coast Down
Delay
Off (9) 10-
3600
9-(Off) Get/Set 40044
18.13.3 Common Services
Service
Code
Implemented for Service Name
Class Level Instance Level
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
18.14 Dual Settings Object (74HEX – 1 Instance)
18.14.1 Class Attributes (Instance 0)
Attribute
ID
Name DeviceNet
Data Type
Data Value Access Rule
1 Revision UINT 1 Get
18.14.2 Instance Attributes (Instance 1)
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
1 DA: Initial Voltage
/
DA: Initial Current
10-80 %
of full
voltage /
100-400
% of FLA
30
/
100 % of
FLA
Get/Set 40049
2 DA: Current Limit 100-700 400 % of
FLA
Get/Set 40050
3 DA: Acceleration
Time
1-90 10
(Seconds)
Get/Set 40051
