171 • HRVS-DN Communication (DeviceNet™)
_______________________________________________________________________________________________
Attribute
ID
Name DeviceNet
Data Type
Data Value Access
Rule
100 Number of Valid Reads
(since power up)
UDINT 0 Get
101 Number of Read Errors
(since power up)
UDINT 0 Get
102 Number of Read Timeouts
(since power up)
UDINT 0 Get
110 Number of Valid Write
(since power up)
UDINT 0 Get
111 Number of Write Errors
(since power up)
UDINT 0 Get
112 Number of Write Timeouts
(since power up)
UDINT 0 Get
18.9.3 Common Services
Service
Code
Implemented for Service Name
Class Level Instance Level
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
32
HEX
No Yes Clear Counters
18.10 Solcon Input Object (70HEX – 1 Instance)
18.10.1 Class Attributes (Instance 0)
Attribute
ID
Name DeviceNet
Data Type
Data Value
Access
Rule
1 Revision UINT 1 Get
18.10.2 Instance Attributes (Instance 1)
Attribute
ID
Name Description Access
Rule
Modbus
Address
1 Logic Status Logic Status of HRVS-DN: Get 40257
2 Hardwired inputs Discrete Hardwired control
inputs
Get 40258
3 Relays d0 - Immediate,d1- End Of
Acc, d2 - Fault relay
Get 40259
4 Voltage Line voltage, % of rated
voltage
Get 40260
5 I1_amp Current of phase 1, Ampere Get 40261
6 I2_amp Current of phase 2, Ampere Get 40262
7 I3_amp Current of phase 3, Ampere Get 40293
8 Reserved Get 40264
9 Dip_Switch d15..d8: Reserved.
d7: Setting Lock - (right-
most)
d6: Enlarged Setting Ranges
d5: Language Selection.
d4: Language Selection.
d3: Reserved - Must be set
to Off.
d2: Generator Starting - Set
to Off.
d1: Tacho feedback
available (1).
d0: Min (off) / Max display
pages- (left most)
Get 40265
10 Phase_Sequence 1: Correct Phase seq.
0 : Wrong Phase Seq
Get 40266
