173 • HRVS-DN Communication (DeviceNet™)
_______________________________________________________________________________________________
Attribute
ID
Name Description Access
Rule
Modbus
Address
40322
67-76 Trip Hour Array
[10]
List of time (Hour) of the last
10 trips
Get 40323-
40332
77-86 Trip Minute Array
[10]
List of time (Minute) of the
last 10 trips
Get 40333-
40342
87-96 Trip Day Array
[10]
List of time (Day) of the last
10 trips
Get 40343-
40352
97-106 Trip Month Array
[10]
List of time (Month) of the
last 10 trips
Get 40353-
40362
107-116 Trip Year Array
[10]
List of time (Year) of the last
10 trips
Get 40363-
40372
117 Trip Pointer Pointer for the 10 cyclic
above arrays
Get 40373
18.10.3 Common Services
Service
Code
Implemented for Service Name
Class Level Instance Level
0E
HEX
Yes Yes Get Attribute Single
18.11 Main Parameter Object (71HEX – 1 Instance)
18.11.1 Class Attributes (Instance 0)
Attribute
ID
Name DeviceNet
Data Type
Data Value
Access
Rule
1 Revision UINT 1 Get
18.11.2 Instance Attributes (Instance 1)
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
1 Rated Line Voltage 2300-
15000
6600
(Volt)
Get/Set 40001
2 Starter FLC 20-1800 150
(Amp)
Get/Set 40002
3 Motor FLA 20-1800 150
(Amp)
Get/Set 40003
4 Rated Motor Power 50-40000 1000
(KW)
Get/Set 40004
5 Service Factor 100-130% 100 (%) Get/Set 40005
6 Undercurrent Trip 0-90 0 (% of
FLA)
Get/Set 40006
7 Undercurrent Delay 1-40 10
(Second
)
Get/Set 40007
8 Over current Shear
Pin
100-850 850 (%
of FLA)
Get/Set 40008
9 Over current Delay 0-50 5 (0.5
Sec)
Get/Set 40009
10 Overload Class IEC:
5,10,15,20
,25,30
NEMA:
5,10,15,20
,25,30 FLA
IEC
Class
10
Get/Set 40010
11 Overload Protect 0=Disable
1=Enable
While Run
2=Enable
1=Enabl
e While
Run
Get/Set 40011
