155 • HRVS-DN Communication (Profibus protocol)

_______________________________________________________________________________________________

Step 2: Read from Slot number 3 and Index number 2

The following eight bytes are displayed: Register number 0x80 , Register number 0x81, Register number 0x82

and Register number 0x83 (4 words = 8 bytes total)

Figure 55 – Reading 4 following register by Data Request (DPV1)

Read from

Slot: 3

Index: 2

8 byte – (4

Registers)
