Solcon HRVS-DN series User Manual

176 •
_____________________________________________________________________________________________
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
4 DA: Deceleration
Time
0-90 0
(Seconds)
Get/Set 40052
5 DA: Motor FLA 20-1800 150
(Amp.)
Get/Set 40053
18.14.3 Common Services
Service
Code
Implemented for Service Name
Class Level Instance Level
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
18.15 Fault Settings Object (76HEX – 1 Instance)
18.15.1 Class Attributes (Instance 0)
Attribute
ID
Name DeviceNet
Data Type
Data Value Access Rule
1 Revision UINT 1 Get
18.15.2 Instance Attributes (Instance 1)
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
1 UV & PL Auto
Reset
0/1
(0 - No, 1 -
Yes)
0 (No) Get/Set 40057
2 Under Current
Reset
10-120 (&121-
off)
121 (Off) Get/Set 40058
5 ByPass Open
Trip
0/1 (0-Disable,
1-Enable)
1
(Enable)
Get/Set 40059
6 Trip after Bypass 0/1 (0-Disable,
1-Enable)
1
(Enable)
Get/Set 40060
7 By-Pass Auto
Reset
0/1
(0 - No, 1 -
Yes)
0 - No Get/Set 40061
8 Set Curve 0 Flt 0/1 (0-Disable,
1-Enable)
1
(Enable)
Get/Set 40062
9 Power On & No
Start
0/1 (0-Disable,
1-Enable)
1
(Enable)
Get/Set 40063
10 Insulation Alarm 1(Off) – 100
(10Mohm)
1 (Off) Get/Set 40064
11 Insulation Trip 1(Off) – 100
(10Mohm)
1 (Off) Get/Set 40065
12 Phase Sequence 0–Pos, 1–Neg,
2–Ignore
0
(Positive)
Get/Set 40066
18.15.3 Common Services
Service
Code
Implemented for Service Name
Class Level Instance Level
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
