138 • HRVS-DN Communication (ModBus Protocol)
_____________________________________________________________________________________________
16.8 Parameter Settings (4X References)
Parameter settings include all parameters that can be set manually. These parameters determine the modes
of operation of the HRVS-DN. They also set protections level. All parameters are word (two bytes)
parameters. The protocol supports both reading and modifying of (most of) these parameters.
Note: Use function 3 to read the setting parameters.
Any one of these parameters must be set with care. Inappropriate settings of some parameters can
result in damage to both the motor and the HRVS-DN.
The parameters have the following 4x references:
Parameter # Range Default
Main & protect. parameters
Rated Line Voltage 1 2300..15000 6600 (Volt.)
Starter FLC 2 20..1800 150 (Amp.)
Motor FLA 3 20..1800 150 (Amp.)
Rated Motor Power 4 50..40000 1000 (KW)
Service Factor 5 100..130% 100 (%)
Undercurrent Trip 6 0..90 0 (% of FLA)
Undercurrent Delay 7 1..40 10 (Seconds)
Overcurrent Shear Pin 8 100..850 850 (% of FLA)
Overcurrent Delay 9 0..50 5 (0.5 Sec.)
Overload Class 10 IEC 5,10,15,20,25,30 IEC Class 10
NEMA 5,10,15,20,25,30 FLA)
Overload Protect 11 0=Disable 1=Enable While Run
1=Enable While Run
2=Enable
Unbalance Trip 12 10..100, 101 = Off. 20 (%)
Unbalance Delay 13 1..60 5 (Seconds)
Ground Fault Trip 14 10..100, 101 = Off. 20 (% of FLA)
Ground Fault Delay 15 1..60 5 (Seconds)
Undervoltage Trip 16 50..90 70 (%)
Undervoltage Delay 17 1..100 5 (Seconds)
Overvoltage Trip 18 110..125 120 (%)
Overvoltage Delay 19 1..10 2 (Seconds)
Reserved 20..24
Start Parameters
Soft Start Curve 25 0..11 (6..11 are for Tacho only) 1 (Standard).
Pulse Level 26 70 (%of FLA) – 700 (%of FLA) 70% of FLA
Pulse Time 27 0..10 (Tenth Seconds) 0 (No Pulse)
Initial Voltage 28 10..80 30 (% of full voltage)
Initial Current 28 ! 100..400 % of FLA 100 % of FLA
Current Limit 29 100..700 400 (% of FLA)
Acceleration Time 30 1..90 10 (Seconds)
Max. Start Time 31 1..250 30 (Seconds)
Number Of Starts 32 1..10 & (11 = off) 1
Starts Period 33 1..60 20 (Minutes)
