Solcon HRVS-DN series User Manual

157 • HRVS-DN Communication (Profibus protocol)
_______________________________________________________________________________________________
17.7 Numbers of actual data Register for (decimal)
Number Parameter Name Description
1 Logic Status
Logic status of HRVS-DN. 1 indicates:
d15: HRVS-DN Tripped.
d14: Motor Stopped.
d13: Motor in Soft Stop Process.
d12: Motor in Start Process.
d11: Motor is Running.
d10: Motor is running with Closed By_Pass.
d9: Up_To_Speed. Like d10 and I reduced (once) below 115% of
FLA.
d8: Reserved.
d7: Dual_Adjust On.
d6..d0: Reserved.
Note: After by-pass is closed, trip (d15) and running (d11), can be ON
together. See Trip_after_By-Pass setting parameter at fault parameters
page.
2 Hardwired inputs
Discrete Hardwired control inputs:
d15..d8: Reserved.
d7: External fault 2, Terminal 20.
d6: External Fault 1,Terminal 19.
d5: Reserved.
d4: Programmable Input , Terminal 8
d3: Programmable Input, Terminal 7
d2: Start Input. Terminal 6
d1: Soft Stop Input. Terminal 5
d0: Stop Input. Terminal 4
3 Relays d0 - Immediate, d1- End Of Acc, d2 - Fault relay
4 Voltage Line voltage, % of rated voltage.
5
I1_amp Current of phase 1, Ampere.
6 I2_amp Current of phase 2, Ampere.
7 I3_amp Current of phase 3, Ampere.
8
Reserved
9
Dip_Switch
d15..d8: Reserved.
d7: Setting Lock - (right-most)
d6: Enlarged Setting Ranges
d5: Language Selection.
d4: Language Selection.
d3: Reserved - Must be set to Off.
d2: Generator Starting - Set to Off.
d1: Tacho feedback available (1).
d0: Min (off) / Max display pages- (left most)
10
Phase_Sequence 1: Correct Phase seq. 0 : Wrong Phase Seq.
11 Motor Insulation R Motor Insulation Resistance [KOhm]
12 Reserved
13
Reserved
14 Reserved
15 Power Power consumption [KW]
16
Reactive Power Reactive Power consumption [KVAR]
17 Power Factor Power Factor * 100
18 Time Since Last Start Elapsed minutes since last start
19
Frequency Frequency [tenth Hz]
20 Reserved
21 Reserved
22
Reserved
23 Reserved
24 Reserved
25
Logic Status at Power
Fail
Logic Status at Control Pwr Supply turn off.
26 Total Run Time Total Hours of Running Motor.
27 Total Starts Total Number Of Start
28 Last start period Duration of last start, Seconds
29 Last start peak I Peak current during last starting process
