156 • HRVS-DN Communication (Profibus protocol)
_____________________________________________________________________________________________
17.5 Configure the PROFIBUS in the HRVS-DN
All the settings to establish PROFIBUS communication are located under the Communication menu. Follow
the steps below to define the PROFIBUS in the HRVS-DN .
1. Press the MODE button until the following message appears:
OMM. PARAMETERS
- **** -
2. Press SELECT one time and the following message will appear:
COMM. PROTOCOL
PROFIBUS
In this menu, use the up/down arrows to define that the communication will be PROFIBUS.
3. Press SELECT again and the following message will appear:
BAUD RATE
AUTO (PROFIBUS)
4. Press SELECT again and the following message will appear:
PARITY CHECK
AUTO (PROFIBUS)
5. Press SELECT again and the following message will appear:
PROFI.NETWORK ID
3
In this menu, use the up/down arrows to define the PROFIBUS Address of the HRVS-DN.
6. Press SELECT again and the following message will appear:
S.LINK PAR. SAVE
ENABLE
In this menu, use the up/down arrows to define whether to enable/disable writing of parameters via
the PROFIBUS.
7. Press SELECT again and the following message will appear:
SER.LINK CONTROL
ENABLE
In this menu, use the up/down arrows to define whether to enable/disable control via the
PROFIBUS.
8. Press SELECT again a number of times until the following message appears:
Store Settings
COMM. Parameters
Pressing the STORE button stores the parameters in the HRVS-DN memory.
17.6 Watch Dog Definition
The Watch-Dog mechanism can be enabled or disabled only via the PROFIBUS controller.
When the Watch-Dog is enabled, the HRVS-DN will stop the motor when there is a break in
communication between the controller and the device.
