17. HRVS-DN COMMUNICATION (PROFIBUS PROTOCOL)
17.1 Global Parameters:
33: ;=============================================
34: ;==== General DP Keywords ====================
35: ;=============================================
36:
37: GSD_Revision = 5
38: Vendor_Name = "Solcon Ltd"
39: Model_Name = "HRVS-DN"
40: Revision = "1.00"
41: Ident_Number = 0x0BAB
42: Protocol_Ident = 0
43: Station_Type = 0
44: FMS_supp = 0
45: Hardware_Release = "V1.00"
46: Software_Release = "V1.00"
47: Redundancy = 0
48: Repeater_Ctrl_Sig = 2
49: 24V_Pins = 0
Code 1 – Global Parameters in the GSD file
17.2 Operation Mode in PROFIBUS:
HRVS-DN supports both DPV0 and DPV1.
 DPV0 (Cyclic) allows:
o Start and shutdown.
o Read parameters (write parameters are not allowed via DPV0).
 DPV1 allows:
o Everything that DPV0 allows
o Change the cyclic parameters that display via DPV0.
o Write to registers.
17.3 Description of the DPV0 (Cyclic) Frame:
From the Profibus controller to the HRVS-DN two bytes (16 bits) are transferred.
From the HRVS-DN to the controller 40 bytes are transferred.
