39 • Installation of IP00 (OEM Kit) in a Cabinet
_______________________________________________________________________________________________
6.1.1 Low Voltage Section
(1) Control Module should be installed in a convenient place allowing access from every direction (this is
achieved by mounting it on a hinged plate).
(2) Due to fiber optic being a frail conductor, insert the fiber optic wires only at assembly completion.
(3) Avoid fiber optic wires bending or stretching (minimal bending radius of 4 cm).
(4) Avoid fiber optic wires installation near heat source.
(5) Control Module and EPT-Rx cases are well grounded.
Refer to standard cabinet wiring as detailed in section
10 page 87.
6.2 Temperature Range & Heat Dissipation
The HRVS-DN is rated to operate within a temperature range of -10°C (14°F) to + 50°C (122°F).
Relative non-condensed humidity inside the enclosure must not exceed 95%.
ATTENTION!
Operating the HRVS-DN with a surrounding air temperature that is higher than
50ºC will cause derating.
Operating the HRVS-DN with a surrounding air temperature that is higher than
60ºC may cause damage to the HRVS-DN.
During soft start the maximum heat dissipation in Watts is as follows:
2,300V – 24xFLC [W]
3,300V – 72xFLC [W]
4,160V – 72xFLC [W]
6,600V – 72xFLC [W]
10,000V – 120xFLC [W]
11,000V – 120xFLC [W] – for marine applications: 144xFLC [W]
13,800V – 144xFLC [W] – for marine applications: 168xFLC [W]
15,000V – 192xFLC [W]
