130 • Spare Parts
_____________________________________________________________________________________________
15. SPARE PARTS
When ordering spare parts for HRVS-DN specify the model and the serial number of the HRVS-DN as shown
on its label and/or on its documentation.
Recommended spare parts list for a soft starter:
All spare parts are for:
Model: HRVS-DN____ ______ _____ _____ ________
Serial number:____________________
Description Cat. Number
(to be filled by the factory)
Quantity in
standard
soft starter
Recommended
quantity as
spare parts
Complete stack (phase
assembly)
3 1
Firing PCB 3 1
Power supply for firing PCB 3 1
EPT-Rx TRAF540964 (identical for all models) 1 1
EPT-Tx 1 1
Current transformer …/2 3 3
Control module.
Order with all options
installed)
1 1
Firing transformer
Or
DC power supply
1 1
Fiber optic wires 10m
Set of support rods for
disassembling phase module
for HRVS-DN up to 6.6kV
TOOL00002 - 1
Low voltage components
spare parts. (terminal blocks,
indication lights, fuses, etc…)
1
Line and Bypass
Contactors/VCBs
2 1
