158 • HRVS-DN Communication (Profibus protocol)
_____________________________________________________________________________________________
Number Parameter Name Description
30
Time to start After too many starts trip, Seconds
31 Total trips Total number of trips
32
Last trip number
# of the fault that caused trip.
# Fault
01: Over Temperature
02: Over current / Shear pin
03: Overload
04: Under Current
05: Under / No Voltage
06: Over Voltage
07: Phase Loss
08: Phase Sequence
09: Wrong Connection or Shorted SCR.
10: Long Start Time
11: Set Curve to 0
12: External Fault 1 (Input # 3)
13: External Fault 2 (Input # 4)
14: Wrong Parameters
15: Mains ON & No Start Signal
16: Too Many Starts
17: Currents Unbalance
18: Insulation
19: Ground Fault
20: Open By-Pass
21: Frequency out of range
22: Comm Port Failure
23: Set Clock
24: Coast Down Time
33 Pre Trip Current at trip time, % of FLA
34 Reserved
35 Reserved
36 Reserved
37 Reserved
38 Reserved
39 Thermal Capacity Simulated winding temperature, %. 100% = trip
40 Reserved
41 Clk Hour Setting can be done at setting # 130
42 Clk Minute Setting can be done at setting # 131
43 Clk Month Setting can be done at setting # 132
44 Clk Date Setting can be done at setting # 133
45 Clk Year Setting can be done at setting # 134
46 Reserved
47 KWH_LS KWH dword parameter: LS word
48 KWH_MS KWH dword parameter: MS word
49 KVARH_ LS KVARH dword parameter: LS word
50 KVARH_MS KVARH dword parameter: MS word
51
Reserved
52
Reserved
53
Reserved
54
Reserved
55
Reserved
56
Reserved
57 Trip Array 1 List of last 10 Trip
58 Trip Array 2 List of last 10 Trip
59 Trip Array 3 List of last 10 Trip
60 Trip Array 4 List of last 10 Trip
61 Trip Array 5 List of last 10 Trip
62 Trip Array 6 List of last 10 Trip
63 Trip Array 7 List of last 10 Trip
64 Trip Array 8 List of last 10 Trip
65 Trip Array 9 List of last 10 Trip
66 Trip Array 10 List of last 10 Trip
