4) Measure the voltage between the terminals using the multi-circuit tester as indicated in the following table. If the
voltage is not within the specified value, replace the regulator/rectifier with a new one. Refer to “Regulator /
Rectifier Construction (Page 1J-8)”.
NOTE
If the tester reads 1.4 V and below when the tester probes are not connected, replace its battery.
Special tool
: 09900–25008 (Multi-circuit tester set)
Tester knob indication
Diode test ( )
Unit: V
5) Connect the regulator/rectifier couplers and bind the clamp.
Battery Components
B718H11A06007
Battery Charging
B718H11A06008
Initial Charging
Filling electrolyte
NOTE
When filling electrolyte, the battery must be
removed from the vehicle and must be put on
the level ground.
B1
B2
B3
B/R2
B/R1
B/W1
B/W2
I718H11A0034-01
(+) probe of tester to:
B/R
1
B/R
2
B
1
B
2
B
3
B/W
1
B/W
2
(–) probe of
tester to:
B/R
1
— 0 0.2 – 0.8 0.2 – 0.8 0.2 – 0.8 0.4 – 1.0 0.4 – 1.0
B/R
2
0 — 0.2 – 0.8 0.2 – 0.8 0.2 – 0.8 0.4 – 1.0 0.4 – 1.0
B
1
* * — 0.6 – 1.2 0.6 – 1.2 0.2 – 0.8 0.2 – 0.8
B
2
* * 0.6 – 1.2 — 0.6 – 1.2 0.2 – 0.8 0.2 – 0.8
B
3
* * 0.6 – 1.2 0.6 – 1.2 — 0.2 – 0.8 0.2 – 0.8
B/W
1
* * 0.3 – 1.0 0.3 – 1.0 0.3 – 1.0 — 0
B/W
2
* * 0.3 – 1.0 0.3 – 1.0 0.3 – 1.0 0 —
*1.4 V and more (tester’s battery voltage)
1. Anode plates 5. Stopper
2. Separator (Fiberglass plate) 6. Filter
3. Cathode plates 7. Terminal
4. Upper cover breather 8. Safety valve
1
3
2
4
5
6
7
8
I649G11A0046-03
