Suzuki GSF1250 - Repair Instructions; Headlight Components; Lighting Systems

Lighting Systems: 9B-1
Body and Acc essories
Lighting Systems
Repair Instructions
Headlight Components
B718H19206001
GSF1250/A
GSF1250S/SA
4
3
2
1
5
I718H1920047-02
1. Headlight rim 3. Headlight bulb (12 V 60/55 W, H4) 5. Position light bulb (12 V 5 W)
2. Headlight unit 4. Headlight housing
3
4
4
1 2
3
I718H1920048-02
1. Headlight low beam bulb (12 V 55 W, H7) 3. Position light bulb (12 V 5 W x 2)
2. Headlight highbeam bulb (12 V 55 W, H7) 4. Socket
