SV 977D User Manual - Appendixes
Table A.4. Profile parameters
Group name
#1
code
#7
code
#S
code
Code description
Filter type in profile n
in SLM mode
F
1:n Z filter for profile n
2:n A filter for profile n
3:n C filter for profile n
5:n B filter for profile n
Detector type in profile n in
SLM mode
C
0:n - Impulse detector in profile n
1:n - Fast detector in profile n
2:n - Slow detector in profile n
Logger type in profile n
in SLM mode
B
x:n - x - sum of the following flags:
1 - logger with Peak values in profile n
2 - logger with Max values in profile n
4 - logger with Min values in profile n
8 - logger with RMS values in profile n
Filter type in profile n
in VLM mode
I
0:n HP filter for profile n
1:n HP1 filter for profile n
2:n HP3 filter for profile n
3:n HP10 filter for profile n
4:n Vel11 filter for profile n
5:n Vel3 filter for profile n
6:n Vel10 filter for profile n
7:n VelMF filter for profile n
8:n Dil1 filter for profile n
9:n Dil3 filter for profile n
10:n Dil10 filter for profile n
21:n Wh filter for profile n
Detector type in profile n in
VLM mode
E
0:n - 100ms detector in profile n
1:n - 125ms detector in profile n
2:n - 200ms detector in profile n
3:n - 500ms detector in profile n
4:n - 1.0s detector in profile n
5:n - 2.0s detector in profile n
6:n - 5.0s detector in profile n
7:n - 10.0s detector in profile n
Logger type in profile n
in VLM mode
G
x:n - x - sum of the following flags:
1 - logger with Peak values in profile n
2 - logger with P–P values in profile n
4 - logger with Max values in profile n
8 - logger with RMS values in profile n
