Svantek SV 977D User Manual

209
SV 977D User Manual - Appendixes
Table B.5. User’s text
Word
number
Name
Comment
0
0nn03h
03h = block identifier
0nnh = block length in words
1..
TitleText
comment text; ASCII character row (terminated by zero byte)
Table B.6. Information about the instrument name
Word
number
Name
Comment
0
0nn58h
58h = block identifier
0nnh = block length in words
1
UnitNameID
instrument name identifier (text "UN")
2..
UnitName
ASCII character row (terminated by zero byte) specifying the
instrument name
…
reserved
Table B.7. Measurement parameters
Word
number
Name
Comment
0
0nn04h
04h = block identifier
0nnh = block length in words
1
MeasureStartDate
start date of the measurement
2
MeasureStartTime
start time of the measurement
3
DeviceMode
measurement mode:
0 – vibration measurement mode
1 – sound measurement mode
4
DeviceFunction
measurement function
1 – Level Meter
2 – 1/1 Octave
3 – 1/3 Octave
6 – FFT
7 – Tonality
8 – RT60
19 - STIPA
5
MeasureInput
measurement Input type:
2 – measurement with the microphone
5 – measurement with the vibration accelerometer
6
Range
measurement range:
1 – Low
2 – High
7
StatDet
for sound measurement mode:
0 – measurement of statistical results with the linear detector
1 – measurement of statistical results with the exponential
detector
