CHAPTER 10 Troubleshooting
Sysmex XE-5000 Instructions for Use 10-37
Revised April 2007
3. FCM Sheath Injector
This program performs test operation of the FCM sheath
injector and sets the motor in the correct initial position.
Execute this test when a “FCM Sheath Motor Error” occurs
and analysis cannot be performed. If the test is normally
completed, analysis will be possible after the system enters
the READY status.
1. From the Main Menu screen on the Main Unit, select
“Test” on the function menu.
The Test Menu screen will appear.
2. Select “Motor” on the function menu of the Test Menu
screen.
The Motor Test screen will appear.
3. Select “3. FCM Sheath Injector” by moving the cursor
with or key on the Motor Test screen.
4. Select “Execute” on the function menu of the Motor Test
screen. The FCM Sheath Injector will start running, and
the Testing screen will appear.
5. When the analysis operations are completed, the motor
will return to the initial position.
6. To cancel the motor test, select “Cancel” on the function
menu, or press the RETURN key.
4. Rinse Motor
This program performs test operation of the rinse cup motor
and sets the motor in the correct initial position.
Execute this test when a “Rinse Motor Error” occurs and
analysis cannot be performed. If the test is normally
completed, analysis will be possible after the system enters
the READY status.
1. From the Main Menu screen on the Main Unit, select
“Test” on the function menu.
The Test Menu screen will appear.
2. Select “Motor” on the function menu of the Test Menu
screen.
The Motor Test screen will appear.
3. Select “4. Rinse Motor” by moving the cursor with or
key on the Motor Test screen.
4. Select “Execute” on the function menu of the Motor Test
screen. The rinse cup motor will start running, and the
Testing screen will appear.
5. When rinsing is completed, the motor will return to the
initial position.
6. To cancel the motor test, select “Cancel” on the function
menu, or press the RETURN key.
