CHAPTER 3 Design and Function
Sysmex XE-5000 Instructions for Use 3-1
Revised April 2007
3. Design and Function
3.1 Overview
1Main Unit
Analyzes and controls samples.
2 Information Processing Unit (IPU)
Processes data which it receives from the Main Unit.
3 Ledger printer (option)
Prints lists of analysis information or results.
4 Color graphic printer (option)
Prints a hardcopy of analysis results or screen of histograms, scattergrams, etc.
5 Pneumatic unit
Supplies pressure and vacuum used by the Main Unit.
6 Sampler unit
Supplies samples to the Main Unit automatically.
7 Data printer (option)
Prints analysis data in the examination ticket format.
1
3
7 6
5
4
2
