CHAPTER 6 Operation
Sysmex XE-5000 Instructions for Use 6-11
Revised April 2007
6.10 Pressure and vacuum gauges check
The pressure and vacuum gauges should reach their
specified levels approximately 30 seconds after the power of
the Main Unit is turned ON.
Confirm that the gauges indicate the values shown below. If
they do not, adjust them to the acceptable range.
(Only the pressure can be adjusted on the Pneumatic Unit.
See “Chapter 9: Cleaning and Maintenance” for adjustment
procedure.)
6.11 Logging on the Main Unit
When the background check is completed, the logon screen is
displayed on the Main Unit LCD screen.
Enter the registered logon name and password, and select
the “OK” on the function menu of the logon screen.
Use the and keys to changeover the input parameter.
By executing logon, the menu corresponded to the permission
set at the Information Processing Unit (IPU) will become
executable. See “Chapter 5: Instrument Setup” in the
Software Guide.
6.12 Auto output settings check
If Auto Output is desired, before starting an analysis, make
sure that the instrument is set to automatically transmit/print.
See “Chapter 5: Instrument Setup” in the Software Guide.
6.13 Quality control
Quality control ensures the reliability of the instrument and
reagents. QC will be used for long-term monitoring of the
stability of analysis values. It can also detect problems early,
or prevent them entirely.
Always run the quality control before analyzing samples. For
details, see “Chapter 7: Quality Control”.
Pressure 0.25±0.03 MPa
Vacuum -0.05 MPa or higher
PRESSURE
VACUUM
Next No.123456789012346
DP No. 123456789012345
C D N R
Manual
OK
Not Ready
Logon Name
Password
Num
DP
Xm
