RUN MED: Service & Maintenance Manual - rev. 1.0
Page 7.24
Figure 7.17-6
11. Remove the drive-belt h by pulling it away
from the motor pulley.
Figure 7.17-7
12.
its the range of motion of the
running deck at the front, using a 5-mm hex
Back off the two screws i of the system
which lim
wrench.
During reassembly, lock down the
screws “i” using torque wrench set for 9
Nm.
Figure 7.17-8
13. Back off the 4 screws
in
7.17-7), which secure the running deck to the
ench.
14. Remove the running deck from the side.
j (there will be another
2 on the front, if the machine does not
corporate the system shown in Figure
frame, using a 6-mm Allen wr
During reassembly, lock down the
screws using “j” torque wrench set for
20 Nm.
Continued on following page →
