CLRC Mode
6-72
CLRC Mode Clear Status Bits
SYNTAX OPTIONS OPCODE OBJMODE RPT CYC
CLRC mode 0010 1001 CCCC CCCC X − 1, 2
CLRC SXM 0010 1001 0000 0001 X − 1
CLRC OVM 0010 1001 0000 0010 X − 1
CLRC TC 0010 1001 0000 0100 X − 1
CLRC C 0010 1001 0000 1000 X − 1
CLRC INTM 0010 1001 0001 0000 X − 2
CLRC DBGM 0010 1001 0010 0000 X − 2
CLRC PAGE0 0010 1001 0100 0000 X − 1
CLRC VMAP 0010 1001 1000 0000 X − 1
Description Clear the specified status bits. The ”mode” operand is a mask value that
relates to the status bits in this way:
“Mode” bit Status Register Flag Cycles
0 ST0 SXM 1
1 ST0 OVM 1
2 ST0 TC 1
3 ST0 C 1
4 ST1 INTM 2
5 ST1 DBGM 2
6 ST1 PAGE0 1
7 ST1 VMAP 1
Note: The assembler will accept any number of flag names in any order.
Flags and
SXM
Any of the specified bits can be cleared by the instruction.
Modes
OVM
TC
C
INTM
DBGM
PAGE0
VMAP
Repeat This instruction is not repeatable. If this instruction follows the RPT
instruction, it resets the repeat counter (RPTC) and executes only once.
