Memory Map
1-8
Figure 1−2. TMS320C28x High-Level Memory Map
Vectors in RAM M0
(VMAP = 0)
Program
Block M0 1 K × 16
Block M1 1 K × 16
Vectors (VMAP = 1)
Data
Memory or
Peripherals
Reserved
(Reset)
Block M1 1 K × 16
Vectors in RAM M0
(VMAP = 0)
Block M0 1 K × 16
<−SP
0000
3FF
400
7FF
3F 0000
FFFF FFFF
1000
9FF
800
Memory or
Peripherals
Reserved
3F FFFF
A000
Low 64K
C2xLP
Compatible
Data Space
High 64K
C2xLP
Compatible
Program
Space
See the data sheet for your specific device for details of the exact memory
map.
