SBF 8bitOffset,EQ/NEQ/TC/NTC
6-318
SBF 8bitOffset,EQ/NEQ/TC/NTC Short Branch Fast
SYNTAX OPTIONS OPCODE OBJMODE RPT CYC
SBF 8bitOffset,EQ 1110 1100 CCCC CCCC 1 − 4/4
SBF 8bitOffset,NEQ 1110 1101 CCCC CCCC 1 − 4/4
SBF 8bitOffset,TC 1110 1110 CCCC CCCC 1 − 4/4
SBF 8bitOffset,NTC 1110 1111 CCCC CCCC 1 − 4/4
Operands 8bitOffset 8-bit signed immediate constant offset value (−128 to +127 range)
Syntax
Description Flags Tested
NEQ
Not Equal To Z = 0
EQ
Equal To Z = 1
NTC
Test Bit Not Set TC = 0
TC
Test Bit Set TC = 1
Description
Short fast conditional branch. If the specified condition is true, then
branch by adding the signed 8-bit constant value to the current PC value;
otherwise continue execution without branching:
If (tested condition = true) PC = PC + signed 8-bit off-
set;
If (tested condition = false) PC = PC + 1;
Note: The short branch fast (SBF) instruction takes advantage of dual pre−fetch queue
on the C28x core that reduces the cycles for a taken branch from 7 to 4:
If (tested condition = true) then the instruction takes 4 cycles.
If (tested condition = false) then the instruction takes 4 cycles.
Flags and
Modes
None
Repeat
This instruction is not repeatable. If this instruction follows the RPT
instruction, it resets the repeat counter (RPTC) and executes only once.
