C28x CPU + FPU + VCU + TMU and CLA
1 - 8 TMS320F2837xD Microcontroller Workshop - Architecture Overview
C28x CPU + FPU + VCU + TMU Pipeline
C28x CPU + FPU + VCU + TMU Pipeline
Floating Point Unit, VCU and TMU has an unprotected pipeline
i.e. FPU/VCU/TMU can issue an instruction before previous instruction has
written results
Compiler prevents pipeline conflicts
Assembler detects pipeline conflicts
Performance improvement by placing non-conflicting
instructions in floating-point pipeline delay slots
F
1
F
2
D
1
D
2
R
1
R
2
E
W
F28x Pipeline
Fetch Decode Read Exe Write
Floating-point math operations, conversions between integer and floating-
point formats, and complex MPY/MAC require 1 delay slot – everything else
does not require a delay slot (load, store, max, min, absolute, negative, etc.)
Load
Store
0 delay slot instruction
1 delay slot instruction
D R E
1
E
2
/W
VCU / TMU Instruction
D R E
1
E
2
/W
FPU Instruction
Floating-point unit (FPU), VCU and TMU operations are not pipeline protected. Some
instructions require delay slots for the operation to complete. This can be accomplished by insert
NOPs or other non-conflicting instructions between operations.
In the user’s guide, instructions requiring delay slots have a ‘p’ after their cycle count. The 2p
stands for 2 pipelined cycles. A new instruction can be started on each cycle. The result is valid
only 2 instructions later.
Three general guideslines for the FPU/VCU/TMU pipeline are:
Math MPYF32, ADDF32,
SUBF32, MACF32,
VCMPY
2p cycles
One delay slot
Conversion I16TOF32, F32TOI16,
F32TOI16R, etc…
2p cycles
One delay slot
Everything else* Load, Store, Compare,
Min, Max, Absolute and
Negative value
Single cycle
No delay slot
* Note: MOV32 between FPU and CPU registers is a special case.
