Textron JACOBSEN Eclipse 2 - Check and Adjustment Specifications; Specifications

5-2 4262930-Rev A
POWER TRAIN
5
Specifications
Check and Adjustment Specifications
Specification
Traction Drive (Transfer) Belt Maximum Deflection
with 3.5–6.3 lb (15.6–28.0 N) of Force Applied at the
Midpoint between Pulleys
in. (mm) 0.14 (3.5)
Traction Drive (Final) Belt Maximum Deflection with
12.5–15.2 lb (55.6–67.6 N) of Force Applied at the
Midpoint between Pulleys
in. (mm) 0.10 (2.5)
