8-12 4262930-Rev A
CUTTING UNIT
8
Mechanical Troubleshooting
Cutting Unit
Condition Probable Cause Remedy
Reel drive does not engage when
Operator Presence Control (OPC) bail is
engaged.
System voltage too low. Check system charge. (See “Battery Pack
Test” on page 4-45.)
Mow switch not engaged. Engage mow switch.
Reel motor harness connector not
connected.
Connect reel motor harness connector.
(See “Reel Motor” on page 4-62.)
Reel motor harness not connected at
controller.
Connect reel motor harness at controller.
(See “Reel Control Unit” on page 4-67.)
OPC cable misadjusted. Adjust OPC cable. (See “OPC Cable” on
page 6-10.)
Bail lever not properly calibrated. Calibrate bail lever. (See “Bail Lever
Calibration” on page 4-43.)
Mow switch faulty. Test mow switch. (See “Mow Switch Test”
on page 4-49.)
Bail potentiometer faulty. Test bail potentiometer. (See “Bail
Potentiometer Test” on page 4-55.)
Reel motor controller faulty. Substitute with a known good reel motor
controller.
Reel motor faulty. Test/replace reel motor. (See “Reel Motor
Test” on page 4-53.)
Reel drive does not reach full speed. Reel motor faulty. Test/replace reel motor. (See “Reel Motor
Test” on page 4-53.)
Bedknife-to-reel contact too tight. Check bedknife-to-reel adjustment. (See
“Bedknife-to-Reel Adjustment” on
page 8-14.)
Speed paddle not properly calibrated. Calibrate speed paddle. (See “” on
page 4-43.)
Bail lever not properly calibrated. Calibrate bail lever. (See “Bail Lever
Calibration” on page 4-43.)
