SPECIFICATIONS AND GENERAL INFORMATION
2
Component Location
Gen-Set Models
See Figures 2-3 and 2-4.
!
CAUTION
Figure 2-3: Component Location—Front
Figure 2-4: Component Location—Rear
Become familiar with operator controls, machine
components, and correct operating procedures
before beginning repair procedures.
1Operator Handle 8Front Roller
2Key Switch 9Traction Motor Controller
3 Belt Cover 10 Reel Motor Controller
4 Traction Motor 11 Gen-Set
5 Reel Counterweight 12 Engine
6 Reel 13 Park Brake Lever
7 Floating Head Frame
Roller
TN4411
1
2
3
5
4
6
7
8
12
10
11
13
9
1 Speed Control Paddle 5 Kickstand
2 Operator Presence Control
(OPC) Bail
6 Product Identification Plate
3 LCD Controls and Display 7 Traction Drum
4 Reel Motor 8 Mow Switch
1
TN4412
2
3
4
5
6
7
8
