Textron JACOBSEN Eclipse 2 - Repair Specifications; Specifications; Test and Adjustment Specifications

ELECTRICAL
4262930-Rev A 4-3
4
Specifications
Test and Adjustment Specifications
Repair Specifications
Specification
Ceramic Resistor Resistance at 68° F ohms 5 ± 5%
120-Ohm Resistor Connector Resistance at 68° F
ohms 120 ± 10%
Throttle Potentiometer Low End Resistance at 68° F
ohms 18.9–35.1
Throttle Potentiometer High End Resistance at 68° F
ohms 3710–6890
Bail Potentiometer Resistance at 68° F
ohms 3640–6760
Specification
Battery Pack Fuse Nut Torque lb-in. (N·m) 25 (2.8)
Generator Engine Shaft Screw Torque
lb-ft (N·m) 20.4 (27.7)
Generator Mounting Screw Torque
lb-in. (N·m) 68 (7.7)
Generator Adapter Plate Mounting Screw Torque
lb-ft (N·m) 14.4 (9.5)
Generator Cover Mounting Screw Torque
lb-in. (N·m) 68 (7.7)
