ELECTRICAL
4262930-Rev A 4-5
4
Gen-Set Models
!
CAUTION
Figure 4-2
Become familiar with operator controls, machine
components, and correct operating procedures
before beginning repair procedures.
1 Speed Control Paddle 7 Traction Motor
2 Mow Switch 8 Traction Motor Controller
3 Engine On/Off Switch 9 Reel Motor Controller
4 Reel Motor 10 Gen-Set
5 LCD Display and Controls 11 30A Fuse
6Key Switch
TN4412, TN4411
1
4
2
6
7
10
8
9
5
11
3
To Next Page
