10-2 4262930-Rev A
ACCESSORIES
10
Specifications
Check and Adjustment Specifications
Repair Specifications
Specification
Turf Groomer Eccentric Mounting Screw Torque lb-ft (N·m) 8–10 (10.8–13.6)
Turf Groomer Belt Tension Link Mounting Screw Torque
lb-ft (N·m) 20 (27.1)
Specification
Solid Front Roller Assembly Maximum Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Solid Tube Front Roller Lock Nut Torque
lb-ft (N·m) 10–30 (13.5–40.6)
Solid Tube Front Roller Shaft-to-Bearing Rotational
Resistance
lb-in. (N·m) 0–1 (0–0.11) with No End Play
Solid Tube Front Roller Assembly Maximum
Rotational Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Grooved Front Roller Lock Nut Torque
lb-ft (N·m) 10–30 (13.5–40.6)
Grooved Front Roller Shaft-to-Bearing Rotational
Resistance
lb-in. (N·m) 0–1 (0–0.11) with No End Play
Grooved Front Roller Assembly Rotational Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Grooved Disc Roller Assembly Maximum Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Grooved Segmented Front Roller Jam Nut Torque
lb-ft (N·m) 70 (95)
Grooved Segmented Front Roller Assembly Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Push Broom Assembly Rod-To-Cam Gap
in. (mm) 0.25 (6.3)
