3-2 4262930-Rev A
ENGINE
3
Specifications
General Engine Specifications
Repair Specifications
Specification
Manufacturer/Model Honda/GX120
Engine Type 4-Stroke, Overhead Valve, Single
Cylinder
Displacement
cu in. (cc) 7.3 (118)
Bore x Stroke
in. (mm) 2.4 x 1.7 (60 x 42)
Cooling System Forced Air
Ignition System Transistorized Magneto
PTO Shaft Rotation Counterclockwise
Recommended Spark Plug BPR6ES (NGK)
W20EPR-U (ND)
Spark Plug Gap
in. (mm) 0.028–0.031 (0.7–0.8)
Specification
Engine Mounting Carriage Bolt Torque lb-ft (N·m) 13 (17.7)
