1-6 4262930-Rev A
SAFETY
1
Figure 1-6
5. Disconnect battery pack connector (5).
)
Figure 1-7
6. Lower and hold the kickstand (7) against the ground.
Grab lower part of handle at base (6), and pull up
and back until the mower rests securely on the
kickstand.
Gen-Set Models
See Figures 1-8 through 1-10.
!
WARNING
Figure 1-8
1. Release the Operator Presence Control (OPC) bail (2).
2. Engage the park brake lever (1).
3. Move key switch (3) to the off position and remove
key.
TN4414
5
TN4454
7
6
Before cleaning, adjusting, or repairing this
equipment, disengage all drives, engage park
brake, and stop engine to prevent injuries.
When performing maintenance other than
adjustments that require the engine to be
running, disconnect gen-set connector, remove
the spark plug wire, and place the wire away from
the plug to prevent accidental starting and bodily
injury.
TN4388
1
2
3
To Next Page
