Textron JACOBSEN Eclipse 2 - Turf Groomer-Roller Assembly

ACCESSORIES
4262930-Rev A 10-25
10
Turf Groomer—Roller Assembly
Disassembly and Assembly
See Figure 10-32.
Figure 10-32
1 Roller Tube 4 Flat Washer (2) 7 Grease Seal (2) 10 Shaft
2 Jam Nut (2) 5 Ball Bearing (2) 8 Snap Ring (2) 11 Set Screw (4)
3 Lock Washer (2) 6 Nylos Ring (2) 9 Grease Fitting (2) 12 Nut (4)
TN4532
1
2
3
4
5
6
7
8
9
10
12
11
