Textron JACOBSEN Eclipse 2 - Backlapping Procedure; Battery Tray Adjustment; Engine Fore;Aft Adjustment

CUTTING UNIT
4262930-Rev A 8-15
8
Battery Tray Adjustment
See Figure 8-6.
1. Park the mower safely. (See “Park Mower Safely” on
page 1-5.)
2. Remove battery pack. (See “Battery Pack” on
page 4-56.)
Figure 8-6
3. Loosen nuts (1) and slide battery tray (2) forward to
increase the weight over the front roller.
4. Move battery tray (2) backward to decrease the
weight over the front roller.
5. Tighten nuts (1) and install battery pack. (See
“Battery Pack” on page 4-56.)
Engine Fore/Aft Adjustment
See Figure 8-7.
1. Park the mower safely. (See “Park Mower Safely” on
page 1-5.)
Figure 8-7
2. Loosen four engine mount nuts (2) and slide engine
assembly (1) forward to increase the weight over the
front roller.
3. Move engine assembly (1) backward to decrease the
weight over the front roller.
4. Tighten engine mount nuts (2).
Backlapping Procedure
See Figures 8-8 through 8-14.
Whenever a reel and bedknife have been ground, or a
new reel or bedknife has been installed, the assembled
reel should be backlapped.
1. Check for damage to the bedknife and reel blades.
(See “Reel and Bedknife Inspection” on page 8-13.)
2. Determine if backlapping or grinding will restore the
proper cutting edge.
3. For optimum performance, use a bedknife grinder to
touch up the blade, then reassemble and adjust the
bedknife to the reel. (See “Bedknife-to-Reel
Adjustment” on page 8-14.)
4. Start the mower.
Figure 8-8
Figure 8-9
1
2
TN0780
TN4401
2
1
Required Tools and Materials
• Lapping Compound (180 Grit)
• Long-Handled Brush
TN4388
6
3
4
7
1
2
5
TN4478
