HANDLE AND CONTROLS
4262930-Rev A 6-9
6
Figure 6-19
NOTE
Be sure potentiometer wires are routed through passage
(10) to prevent pinching wires.
3. Install handle assembly (7) and secure with four
screws (8) and nuts (9).
Figure 6-20
4. Apply dielectric grease (Jacobsen PN 365422) to any
connectors removed.
5. Connect potentiometer harness connector (11).
6. Install handle cover. (See “Handle Cover” on
page 6-4.)
TN4432
7
98
10
TN4629
11
