CUTTING UNIT
8
Specifications
General Specifications
Check and Adjustment Specifications
Specification
Height-of-Cut Range (Bench Setting) in. (mm) 1/16–7/16 (1.6–11.1)
High-Profile Cut Yield
in. (mm) 5/32–7/16 (3.96)
Low-Profile Cut Yield
in. (mm) 1/8–7/32 (3.17)
Tournament Cut Yield
in. (mm) 3/32–5/32 (2.38)
Super Tournament Cut Yield
in. (mm) 5/64–7/64 (1.58)
Championship Cut Yield
in. (mm) 1/16 –7/64 (1.58)
Reel Diameter
in. (mm) 5 (127)
Reel Composition Hardened High-Manganese Carbon Steel
Width of Cut
in. (cm) 18 (457), 22 (557.5)
Specification
Bedknife-to-Reel Gap in. (mm) 0.001–0.003 (0.025–0.075)
Reel Bearing Pre-Load
in. (mm) 0.040 (1.0)
Bedknife Front Face Height (minimum)
in. (mm) 0.035 (0.9)
Bedknife Front Face Angle (all bedknives)
degrees 5
Bedknife Top Face Angle (rear relief) (all bedknives
except Super Tournament)
degrees 8–10
Super Tournament Bedknife Top Face Angle
(rear relief)
degrees 5–7
Reel Blade Relief Angle
degrees 45
