172
FUNCTION SETTING USING SETTINGS SCREEN
SETTING THE SHARED FOLDER
The shared folder of data transferred can be set.
1 Tap the of the set item display "Shared folder setting" of "NET-
WORK. "
2 Tap the displayed keyboard, then enter "shared folder", "user" and "password".
3 Setting is completed by tapping the .
SETTING THE PRINT IMAGE OUTPUT
When the is pressed, output of the print image (image data) can be set
to ON or OFF. Before shipment, the default setting is OFF.
1 Tap the of the set item display "Print Image Output" of "NET-
WORK. "
2 Tap the and select "ON" or "OFF."
3 Setting is complete.
* Transferable print images are the image data of 4 layouts set by "SETTING OF EXTERNAL
PRINTER (PRINT EXT)" on page 167. If "Setting of External Printer" has not been done yet,
image data cannot be transferred.
SETTING THE KR-1W DATA OUTPUT
When the is pressed, outputting measurement data to a connected PC,
while simultaneously printing with the internal printer, can be set to ON or OFF. Before ship-
ment, the default setting is OFF.
1 Tap the of the set item display "KR-1W Data Output" of "NET-
WORK."
2 Tap the and select "ON" or "OFF."
3 Setting is complete.
SETTING THE SCREEN SHOT OUTPUT
Screen shot is a function that allows the Analysis Result screen to be output.
In KR-1W, the Analysis Result screen displayed on the main body is outputted in the bit map style.
When the is pressed, outputting the screen shot to a connected PC,
while simultaneously printing with the internal printer, can be set to ON or OFF, Before ship-
ment, the default setting is OFF.
1 Tap the of the set item display "Screen Shot Output" of "NET-
WORK. "
2 Tap the and select "ON" or "OFF."
3 Setting is completed by tapping the .
It is necessary to previously set the user, password and writing authority to the
shared holder of the transferring destination.
Set Condition button
OK button
DATA OUT button
Set Condition button
Setting Change butto
n
DATA OUT button
Set Condition button
Setting Change butto
n
DATA OUT button
Set Condition button
Setting Change butto
n
OK button
