55
BASIC OPERATIONS
BASIC OPERATIONS
PREPARATION BEFORE MEASUREMENT
5 By tapping the button, adjust the position of the z-axis posi-
tion icon for the right/left eyes.
6 At a position where the measuring nozzle is 8-9mm from the cornea, tap the /
button and thereby set the position of the safety stopper.
7 Return to the Measurement screen and confirm that the position of the safety stopper position
icon is changed, push the main unit a little forward by operating the
button of the control panel, and then confirm that a message
“Safety stopper limit” is displayed on the screen. Setting is complete if the main unit does not
go forward any more.
NOTE
At this moment, confirm alternately the distance between the patient’s eye
and the measuring nozzle and the safety stopper screen, and adjust the
position of the z-axis position icon.
Measuring head forward/backward
OK APPLY
8~9mm
Measuring head forward/backward
