Toro Groundsmaster 360 Service Manual

InstallingtheFrontSteeringFork(continued)
B.Securethewheelmotortothesteeringforkwiththe4bolts;tightenthe
boltsfrom128to157N∙m(94to116ft-lb).
C.Securethebulkheadbracket(item11inFigure271)tothesteeringfork
withthe2bolts.
IMPORTANT
Beforeinstallingthetierodend,cleanthetapersofthesteering
forkandtierodend.Ensurethatthetapersarefreeofgrease,oil,
rust,anddirt.Donotuseanti-seizelubricant,whenyouinstallthe
tierodend.
Note:Ifnecessary,tightentheslottedhexnutfurtheruntiltheslotinhexnut
alignswiththeholeinthetierodballjointstud.
8.Connectthetierodend(item1inFigure272)tothefrontsteeringforkwith
theslottedhexnut.Tightenthehexnutfrom48to54N∙m(35to40ft-lb).
Installanewcotterpin.
9.Lubricatethesteeringforkspindlethroughthegreasettingontheaxle.
Greaseshouldpurgefromtheendsofthespindleidentifyingthatthegrease
cavityiscompletelylled.Wipeupexcessgrease.
10.Installthewheelassembly;refertoInstallingtheWheel(page6–14).
WARNING
Failuretomaintainpropertorquecouldresultinfailureorlossof
wheelandmayresultinpersonalinjury.
Maintainthepropertorqueofthewheel-lugnuts.
11.Checkandadjustthewheelalignment;refertoAligningtheWheels(page
6–8).
12.Ensurethatthereisnocontactbetweenthemachinecomponentswhilethe
wheelsmovefromlocktolock.Adjustifnecessary.
Chassis:ServiceandRepairs
Page6–30
Groundsmaster360
16225SLRevC

Toro Groundsmaster 360 Specifications

General

Cutting Width	72 inches
Fuel Type	Diesel
Number of Blades	3
Transmission	Hydrostatic
Turning Radius	0 inches (0 cm) - Zero Turn
Drive System	4WD
Cutting Height	1.5 - 5 inches
