Toshiba B-FV4 Series User Manual

5. MAINTENANCE EO18-33030
5.1 Cleaning
5-7
5. Slide two levers as indicated by the arrows.
6. Open the Paper Guide for cleaning.
7. Use the Scraper to remove adhesive residues from the cutter blade.
8. Use the Cleaner Pen to clean the blade surface.
WARNING!
As the cutter blade is sharp, care should be taken not to injure yourself while cleaning.
Paper Guide
Scraper
Cleaner Pen
Lever Lever

Toshiba B-FV4 Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5 – 40 °C
Storage Temperature	-20 – 60 °C
Power Supply	100-240 VAC, 50/60 Hz
Interfaces	USB, Serial (RS-232)
Media Width	25.4 – 112 mm
