Toshiba B-FV4 Series User Manual

7. B-FV Setting Tool EO18-33030
7.2 Working with B-FV Setting Tool (V1.0.21)
7-10
7.2.3 Navigation Pane
The Navigation pane includes three items: Parameter Setting, Download and Tool. Each item
has its own tabs, and each tab has a Send or Get button. Send is to send your settings to your
printer; Get is to get the current settings of your printer. You can also right-click in the Properties
pane and select Send or Get in the shortcut menu. Each time you click Send, your printer restarts
to apply the change.
Important You can send data via all ports, but can only get data via the USB, COM
and LAN ports.
Parameter Setting
Parameter Setting is used to configure printer settings. It includes three tabs: General, COM and
LAN.
General
The General tab provides general printer settings. It is related to the emulation language you
choose. Each language provides its own properties.
 TPCL
TPCL provides various printing settings, including Image, Supply, Control, Command, Action,
Position Adjustment, BASIC and Destination.

Toshiba B-FV4 Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5 – 40 °C
Storage Temperature	-20 – 60 °C
Power Supply	100-240 VAC, 50/60 Hz
Interfaces	USB, Serial (RS-232)
Media Width	25.4 – 112 mm
