3. REPLACING THE IMPORTANT PARTS EO18-33030
3.3 Replacing the Parts for B-FV4D-GH
3-41
3.3.11 Replacing the Media Holder Lever
1. Refer to Section 3.3.5 to remove the mid cover.
2. Use a Phillips screwdriver to remove the 2 screws.
3. While softly pressing the upper side of the media holder lever, take it off by pulling its lower side.
4. Replace the media holder lever with a new one and then reassemble it in the reverse order of
removal.
Screw
Media Holder Lever

Toshiba B-FV4 Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5 – 40 °C
Storage Temperature	-20 – 60 °C
Power Supply	100-240 VAC, 50/60 Hz
Interfaces	USB, Serial (RS-232)
Media Width	25.4 – 112 mm
