5. MAINTENANCE EO18-33030
5.1 Cleaning
5-6
5.3 Cleaning of the Cutter Module (B-FV4D-GL Series)
WARNING!
Be sure to turn off the power before cleaning the Cutter.
NOTE:
 Please use the Scraper and the Cleaner Pen to clean the Cutter.
 Clean the Cutter every one label roll or at the end of day.
1. Turn the power off.
2. Wipe Cutter Outlet and Cutter Tray with a dry soft cloth.
3. Open the Top Cover.
4. Detach the Cutter Tray from the Cutter Block, then remove the Cutter Block from the printer by lifting it.
Cutter Outlet
Cutter Tray
Cutter Block
Cutter Tray
