1. OUTLINE EO18-33030
1.3 Specifications
1-13
1.3.3 Basic Specifications (for B-FV4D-GL)
Model B-FV4D-GL Series
General
Characteristics
Construction Double walled casing & Clam shell design
Maintenance No tool required to repair thermal head and platen
Paper holder No roll spindle & No paper holder spring
Printer
characteristics
Print method Direct thermal
Resolution 203 dpi (8 dots/mm)
Print width Max. 99.0 mm (3.89”)
Print length Max. 152.4 mm (6.0”)
Print Speed
Cut mode:
50.8 mm/sec. (2”/sec.),
76.2 mm/sec. (3”/sec.),
101.6 mm/sec. (4”/sec.),
127 mm/sec. (5”/sec.),
152.4 mm/sec. (6”/sec.)
RAM 32 MB SDRAM
Flash ROM 16 MB
User area 3 MB
Optional
memory
Max. 16 GB USB
Media sensor Paper End Sensor (Transmissive)
I/F (User
installable)
Serial interface RS-232C
USB 2.0 full Speed
Ethernet interface (10/100 Base)
Barcode Linear
UPC-A, UPC-E, EAN8/13,
UPC-A add on 2&5, UPC-E add on 2&5,
EAN-8/13 add on 2&5,
CODE39, CODE93, CODE128, GSI-128(UCC/EAN128),
NW7, MSI, Industrial 2 of 5, ITF, POSTNET, RM4SCC, KIX-Code,
USPS Intelligent mail barcode, GS1 DataBar
Printer
Language
TPCL (Refer to External Equipment I/F manual)
2D Barcode Data Matrix, PDF417,
QR Code, Maxi Code,
Micro PDF417
Composite
symbol
GS1-128 Composite (CC-A/CC-B/CC-C)
Fonts Times Roman (6 sizes), Helvetica (6 sizes), Presentation (1 size),
Letter Gothic (1 size), Courier (2 sizes), Prestige Elite (2 sizes),
OCR-A (1 type), OCR-B (1 type), Simplified Chinese (1 size)
LED Two LEDs w/ 3 colors (w/ silk screen print of “STATUS”, “1”, and “2”)
Key Feed key (w/ silk screen print of “FEED”)
Switch Power S/W
