Toshiba B-FV4 Series User Manual

1. OUTLINE EO18-33030
1.3 Specifications
1-12
Model B-FV4D-GS Series B-FV4D-TS Series B-FV4D-GH Series
Operating
characteristics
Operating temperature 5C to 40C (41F to 104F) (*1)
Storage temperature -20C to 60C (-4F to 140F)
Operating humidity 25 to 85 % (Non-condensing R.H) (*1)
Storage humidity 10 to 90 % (Non-condensing R.H)
Electrical
AC Adapter
 B-FV4D- GS/TS Series
100 to 240 VAC ± 10%, 47 to 63 Hz
 B-FV4D-GH Series
100 to 240 VAC ± 10%, 50 to 60 Hz
Power consumption (100 to 120 V)
During standby: 0.12 A, 3.7 W maximum
During a print job: 1.0 A, 60 W maximum
Power consumption (200 to 240 V)
During standby: 0.07 A, 3.8 W maximum
During a print job: 0.6 A, 59 W maximum
Inrush Current
100 VAC:  40 A, 240 VAC:  80 A At cold start, maximum load
Agency approvals FCC Class A, C-Tick, CE, TUV-GS, UL, cUL
Environmental
complaint
RoHS,
WEEE
Physical
characteristics
Width 183.8 mm (7.2”) 183.8 mm (7.2”)
Height 166.9 mm (6.5”) 198.7 mm (7.8”)
Depth 226.2 mm (8.9”) 244.5 mm (9.6”)
Weight 1.76Kg (3.8 lb) (Excluding media)
2.2Kg (4.9 lb)
(Excluding media)
Related
products
Options
Full cutter module (B-FV204D-F-QM-R)
Partial cutter module (B-FV204D-P-QM-R)
Peel-off module (B-FV904D-H-QM-R)
External media stand (B-FV904-PH-QM-R)
Bluetooth interface (B-FV704D-BLTH-QM-R)
N/A
Accessories
CD-ROM (1 copy)
Power Adapter (1 pc.)
Quick Installation Manual (1 copy)
Safety Precautions (1 copy)
USB cable (1pc.)
CD-ROM (1 copy)
Quick Installation
Manual (1 copy)
Safety Precautions
(1 copy)
USB cable (1pc.)
NOTES:
*1 Since the adhesive strength of labels becomes higher in hot and humid conditions, the possibility of
label jam increases.

Toshiba B-FV4 Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5 – 40 °C
Storage Temperature	-20 – 60 °C
Power Supply	100-240 VAC, 50/60 Hz
Interfaces	USB, Serial (RS-232)
Media Width	25.4 – 112 mm
