Toshiba B-FV4 Series User Manual

1. OUTLINE EO18-33030
1.3 Specifications
1-14
Model B-FV4D-GL Series
Operating
characteristics
Operating temperature 5C to 35C (41F to 95F) (*1)
Storage temperature -20C to 60C (-4F to 140F)
Operating humidity 30 to 75 % (Non-condensing R.H) (*1)
Storage humidity 10 to 90 % (Non-condensing R.H)
Electrical
AC Adapter
100 to 240 VAC ± 10%, 50 to 60 Hz
Power consumption (100 to 120 V)
During standby: 0.12 A, 3.7 W maximum
During a print job: 1.0 A, 60 W maximum
Power consumption (200 to 240 V)
During standby: 0.07 A, 3.8 W maximum
During a print job: 0.6 A, 59 W maximum
Inrush Current
100 VAC:  40 A, 240 VAC:  80 A At cold start, maximum load
Agency approvals RCM, CE, TUV-GS
Environmental
complaint
RoHS,
WEEE
Physical
characteristics
Width 184.0 mm (7.2”)
Height 198.8 mm (7.8”)
Depth 271.2 mm (10.7”)
Weight 2.8Kg (6.2 lb) (Excluding media)
Related
products
Options
N/A
Accessories
CD-ROM (1 copy)
Quick Installation Manual (1 copy)
Safety Precautions (1 copy)
USB Cable (1pc.)
Scraper (1 pc.)
Cleaner Pen (1 pc.)
Cutter Tray (1 pc.)
NOTES:
*1 Since the adhesive strength of labels becomes higher in hot and humid conditions, the possibility of
label jam increases.

Toshiba B-FV4 Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5 – 40 °C
Storage Temperature	-20 – 60 °C
Power Supply	100-240 VAC, 50/60 Hz
Interfaces	USB, Serial (RS-232)
Media Width	25.4 – 112 mm
