1. OUTLINE EO18-33030
1.3 Specifications
1-10
Model B-FV4T-GS Series B-FV4T-TS Series
Operating
characteristics
Operating temperature
5C to 40C (41F to 104F) (*1)
Storage temperature -20C to 60C (-4F to 140F)
Operating humidity 25 to 85 % (Non-condensing R.H) (*1)
Storage humidity 10 to 90 % (Non-condensing R.H)
Electrical
AC Adapter
100 to 240 VAC ± 10%, 47 to 63 Hz
Power consumption (100 to 120 V)
During standby: 0.07 A, 3.4 W maximum
During a print job: 0.90 A, 49.0 W maximum
Power consumption (200 to 240 V)
During standby: 0.05 A, 3.5 W maximum
During a print job: 0.47 A, 48.1 W maximum
Inrush Current
115 to 230 VAC: 90 A
Agency approvals FCC Class A
C-Tick
CE
TUV-GS
UL, cUL
Environmental
complaint
RoHS
WEEE
Physical
characteristics
Width 220.6 mm (8.7”)
Height 182.0 mm (7.2”)
Depth 278.5 mm (11.0”)
Weight 2.4Kg (5.29 lb) (Excluding media and ribbon)
Related products Options Full cutter module (B-FV204T-F-QM-R)
Partial cutter module (B-FV204T-P-QM-R)
Peel-off module (B-FV904T-H-QM-R)
External media stand (B-FV904-PH-QM-R)
Bluetooth interface (B-FV704T-BLTH-QM-R)
TPH kit (B-FV704-TPH2-QM-R) TPH kit (B-FV704-TPH3-QM-R)
Accessories CD-ROM (1 copy)
Power Adapter (1 pc.)
Quick Installation Manual (1 copy)
Safety Precautions (1 copy)
USB cable (1pc.)
1-inch Ribbon Spindle (2 pcs.)
0.5-inch Ribbon Spindle (2 pcs.)
Paper Support Roller for Outside-wound Media (1 pc.)
NOTES:
*1 Since the adhesive strength of labels becomes higher in hot and humid conditions, the possibility of
label jam increases.
To Next Page
