Toshiba B-FV4 Series User Manual

7. B-FV Setting Tool EO18-33030
7.6 Working with B-FV Setting Tool (V1.0.34)
7-126
6. In the Open dialog box, browse to the folder that contains command files, select them and click
Open. The command files you select must correspond to the emulation language you use.
7. In the list, select the file you want to use. You can only select one file at a time.
8. Click Send to run the command on your printer.
Note If you send a command file and your printer doesn’t respond, it is possible that
the emulation language is not set correctly. Click Sync to get the current setting of
Printer Emulation.

Toshiba B-FV4 Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5 – 40 °C
Storage Temperature	-20 – 60 °C
Power Supply	100-240 VAC, 50/60 Hz
Interfaces	USB, Serial (RS-232)
Media Width	25.4 – 112 mm
