1. OUTLINE EO18-33030
1.6 Supply Specifications
1-22
B-FV4D-GS/TS Unit: mm (inch)
Issue mode
Item
Batch mode
Batch mode
(Tear-off)
Strip mode Cut mode
Media width
(Including backing paper)
25.4 to 118.0 (1.00 to 4.65)
Label width 22.4 to 115.0 (0.88 to 4.53)
Media pitch
Label
10 to 999
(0.39 to 39.3)
25.4 to 152.4
(1.0 to 6.0)
(See NOTE4)
25.4 to 999
(1.0 to 39.3)
(See NOTE2)
Tag
10 to 999
(0.39 to 39.3)
-----
25.4 to 999
(1.0 to 39.3)
(See NOTE2)
Label length
8 to 997
(0.31 to 39.2)
23.4 to 150.4
(0.92 to 5.92)
(See NOTE4)
19.4 to 993
(0.76 to 39.1)
(See NOTE2)
Gap/black mark length 2.0 to 10.0 (0.08 to 0.39)
6.0 to 10.0
(0.24 to 0.39)
Black mark width Min. 8.0 (0.31)
Thickness 0.06 to 0.19 (0.0024 to 0.0075)
Max. outer roll diameter
Ø127 (5.0)
Ø203.2 (8.0): When the optional External Media Stand is used.
Roll direction Outside (standard), Inside
(See NOTE 2)
Inner core diameter 25.4, 38.1, or 76.2 (1.0, 1.5, or 3.0)
(See NOTE 2)
NOTES:
1. To ensure print quality and print head life use only TOSHIBA TEC CORPORATION approved media.
2. When you use inside wound media in cut mode, the specifications are restricted as follows:
- Media pitch (Label): 25.4 mm to 84.2 mm (1.0” to 3.31”)
- Media pitch (Tag): 25.4 mm to 84.2 mm (1.0” to 3.31”)
- Label length: 23.4 mm to 76.2 mm (0.92” to 3.0”)
- Inner core diameter: 76.2 mm (3.0”)
3. When using a media roll of 76.2-mm (3”) inner core diameter, the 3”-Diameter Media Shaft included in the
optional External Media Stand is required.
4. When you use inside wound media in strip mode, the specifications are restricted as follows:
- Media pitch (Label): 25.4 mm to 84.2 mm (1.0” to 3.31”)
- Label length: 23.4 mm to 76.2 mm (0.92” to 3.0”)
B-FV4D-GH Unit: mm (inch)
Issue mode
Item
Batch mode /
Batch mode (Tear-off)
Strip mode
Media width
(Including backing paper)
105 (4.1) +1.0/-1.5
Label width 102 (4.0)
Media pitch 10 to 999 (0.39 to 39.3)
See NOTE 2.
25.4 to 152.4 (1.0 to 6.0)
See NOTE 2.
Label length 8 to 997 (0.31 to 39.2)
See NOTE 2.
23.4 to 150.4 (0.92 to 5.92)
See NOTE 2.
Gap length 2.0 to 10.0 (0.08 to 0.39)
Thickness 0.06 to 0.19 (0.0024 to 0.0075)
Max. outer roll diameter Ø127 (5.0)
Roll direction Outside (standard), Inside
(See NOTE.2)
Inner core diameter 25.4, 38.1
(See NOT
.)
NOTES:
1. To ensure print quality and print head life use only TOSHIBA TEC CORPORATION approved media.
2. When you use inside wound media, the specifications are restricted as follows:
Issue mode Batch mode / Batch mode (Tear-off) Strip mode
Media pitch 10 to 999 (0.39 to 39.3) 25.4 to 86.2 (1.0 to 3.39)
Label length 8 to 997 (0.31 to 39.2) 23.4 to 76.2 (0.92 to 3.0)
Inner core diameter 38.1 (1.5) 38.1 (1.5)
